High Quality Marine Type Fender Pneumatic Rubber Fender for Boat Diameter 0.5m-4.5m Length1.0m-12m Initial Inner Pressure
50kpa, 80kpa Standard ISO17357
Product Description:
Material Advantages:Superior Impact Protection: High-elasticity rubber base combined with air pressure regulation rapidly absorbs berthing impacts, dispersing collision forces to prevent hull coating damage and structural deformation.
Durable and Rugged: Resists seawater corrosion, UV aging, and extreme temperatures (-20°C to 60°C). Withstands prolonged seawater immersion without cracking or delamination, offering significantly longer service life than standard fenders.
Safe and Stable Design: High airtightness with leak-proof valves and pressure monitoring ports ensures stable inflation. Remains fixed without displacement or flipping during berthing, compatible with vessels of varying draft depths.
Convenient Installation and Maintenance: Lightweight and flexible in size, supports multiple mounting methods including suspended and floating installations. Requires only periodic air pressure checks for routine maintenance, keeping operational costs low.
Manufacturing Process:
Precision Cutting: Utilizing CNC laser cutting technology, precise cutting of the material fabric is carried out to ensure a dimensional error of ≤ 1%, meeting the requirements for the formed shape after inflation.
Reinforced Double Stitching: At key seams, double-thread sewing combined with heat-pressed edge sealing technology is employed to enhance the sealing performance and tear resistance, preventing air leakage or thread breakage after inflation.
High-Pressure Heat Bonding: The fabric seams undergo high-temperature and high-pressure heat bonding treatment, achieving high fusion and enhancing the overall structural strength to withstand collisions and impacts in marine environments.
Multi-Layer Coating Treatment: The surface is sprayed with UV protection layer and wear-resistant coating for dual protection, isolating ultraviolet rays and seawater erosion, and prolonging the service life.
Strict Air-Tightness Testing: The finished product undergoes a 24-hour high-pressure inflation test, with a pressure retention rate of ≥ 98%, ensuring no hidden leaks and stable sealing.
Edge Reinforcement Molding: The edges are treated with thickened edge wrapping and reinforced fastening design to strengthen the stressed points and prevent wear and deformation over long-term use.
Features:
Superior anti-collision cushioning: High elasticity material combined with scientific inflation structure, quickly absorbing impact force during collision, effectively protecting the hull and the dock from scratches and damage.
Multiple size compatibility: Covering various specifications from 12×24 Inch to 22×44 Inch, compatible with various types of vessels such as yachts, fishing boats, and speedboats, with strong versatility.
Durable and sturdy: Marine-grade material + reinforced process, resistant to tearing, wear and tear, UV protection, able to withstand long-term exposure to seawater and harsh marine environments.
Convenient use and storage: Rapid inflation, significant reduction in volume after deflation, easily portable with light weight, not occupying too much space on the ship, convenient for storage.
Sealing and leak prevention: Double-line sewing, heat-pressed edge sealing + strict air tightness testing, stable sealing after inflation, long-term use is not prone to leakage, no need for frequent inflation.
Safe and environmentally friendly: Uses odorless and environmentally friendly materials, non-toxic and harmless, no harmful gases released during use, balancing ship protection and environmental safety.
Technical Parameters:
Material: Natural rubber + synthetic rubber composite base material, with built-in high-strength nylon cord reinforcement layer.
Specifications: Diameter 300mm–3000mm, Length 1000mm–10000mm (custom sizes available).
Working Pressure: 0.03~0.15MPa, Burst Pressure ≥0.3MPa.
Accessories: Includes inflation valve, quick-connect coupling, lifting eye, protective sleeve (optional).
Applications:
Superior Impact Protection: High-elasticity rubber base combined with air pressure regulation rapidly absorbs berthing impacts, dispersing collision forces to prevent hull coating damage and structural deformation.
Durable and Rugged: Resists seawater corrosion, UV aging, and extreme temperatures (-20°C to 60°C). Withstands prolonged seawater immersion without cracking or delamination, offering significantly longer service life than standard fenders.
Safe and Stable Design: High airtightness with leak-proof valves and pressure monitoring ports ensures stable inflation. Remains fixed without displacement or flipping during berthing, compatible with vessels of varying draft depths.
Convenient Installation and Maintenance: Lightweight and flexible in size, supports multiple mounting methods including suspended and floating installations. Requires only periodic air pressure checks for routine maintenance, keeping operational costs low.
Support and Services:
After-sales consultation: We provide 24/7 customer service to answer customer questions , such as specification selection, usage methods, and maintenance points.
Regular follow-up visits: The manufacturer may conduct regular follow-up visits to customers to understand the usage and collect customer feedback in order to continuously improve product quality and service levels.
Maintenance guidance: The manufacturer or professional organizations will provide customers with maintenance guidance, including regularly checking for deformation, rust, ; applying rust-preventive oil or corrosion inhibitors after cleaning; and lubricating .
with its excellent quality and attentive service, builds a solid guarantee for your maritime career. Choosing us means choosing safety, efficiency, and worry - free operation. Embark on a new journey of navigation, starting from choosing our product!
Any question please let us know ,our JinCheng maritime will provide you the best service with 7*24 hours ~
